Vallis Schröteri and Surroundings

| 2 Comments

Step 1

Move mouse over sketch to see labels. Click image for larger version.

Observation Notes:

And so, in the spirit of completing one Lunar sketch and observation every 6 months or so, I present Vallis Schröteri. On the night I made this observation, I was very impressed by the rugged terrain in the vicinity of this sinuous rille. The whole area looked like a badly skinned knee in merciful shades of gray. Although Vallis Schröteri was the celebrity, a few other features played staring roles. Mons Herodotus shone brilliantly while the craters Herodotus and Aristarchus stared out like spectacled eyes with the teardrop of Väisälä glistening on the burnished cheek of a nearby highland. Further to the north, Montes Agricola embraced the region like the tip of a rattlesnake's tail.

There was so much to observe and sketch, I couldn't possibly capture it all. I did learn from my previous attempts at white on black Conté sketching and went for a larger illustration. This sketch was prepared on a 9" x 12" sheet of black Canson Mi Tientes pastel paper. I used a blending stump to smooth the pastel where appropriate and to build up brighter tones. The brightest rims are straight attacks with the Conté pencil. The sketch took about 45 minutes at the eyepiece with another 15 minutes of additional touch-up indoors. White on black sketching is really a great way to tackle the moon--especially the terminator. I hope to keep working at it when time permits. I'll still be using pencil and charcoal, but it's nice to have this method accessible when I want it.

Object Information:

Vallis Schröteri is the largest sinuous valley on the Moon. Although hidden in shadow in my sketch, this valley makes its start at a 6 km diameter crater just north of Herodotus crater and widens to 10 km. This area is sometimes referred to as the Cobra's head. It then winds 160 km and narrows to 500 m at it's end. The rille is likely the result of volcanic activity as a lava flow carved its winding path through the landscape. Aristarchus is a remarkably bright crater with a pronounced ray system. It is 40 km in diameter and is believed to be a relatively young 450 million years old.

SubjectVallis Schröteri and Surroundings
ClassificationSinuous Valley, Craters and Mountains
PositionWest
Phase/Age11.7 Days
Size*Vallis Schröteri: 160 km length x 1000 m depth (max)
Herodotus: 35 km dia
Aristarchus: 40 km dia x 3000 m depth
Väisälä: 8 km dia
Dorsum Niggli: 50 km length
Montes Agricola: 160 km length
Mons Herodotus: 5 km dia
Date/TimeApril 28, 2007, 10:00 PM MST (April 29, 2007, 05:00 UT)
Observing Loc.Flagstaff, AZ - Home
InstrumentOrion SVP 6LT Reflector (150 mm dia./1200 mm F/L)
Eyepieces/Mag.10 mm + 2X Barlow (240X)
ConditionsPartly cloudy, calm
SeeingAnt. III
SourcesAtlas of the Moon by Antonín Rükl 2004; Observing the Moon by Gerald North 2000.
* Based on published data.

2 Comments

So you are on the biannual lunar observation schedule as well... :^) That is a simply awesome rendering of Vallis Schröteri; I'm not sure I'd want to visit, though - your description makes it sound like a rather hazardous place. Skinned knees, rattlesnakes and tears. Oh my!

I'll have to try sketching lunar features on black paper sometime - I think I still have my white Conté pencil somewhere, though its not much more than a stump at this point.

Eric

Thanks Eric. Yeah, two Lunar sketches a year seems to be about all I can handle these days. The Lunar terminator is truly a force to be reckoned with...which probably influenced my choice of descriptions. I find it very challenging, yet extremely rewarding at the same time.

You know, those Conté pencils or General's white charcoal pencils are pretty affordable. I think you owe it to yourself* to drop a few quarters on one.

May the winds blow gently,
Jeremy

*also 'me' since I want to see what you come up with :)
