Messier 17 - The Swan Nebula

| 5 Comments


Click above image to view larger sketch.

Observation Notes:

From Anderson Mesa, this nebula appears much larger than the typical swan shape that I see from home--even without the UltraBlock filter. The back of the swan is the brightest portion with the neck second brightest. The head appears to have a crest, and fainter wings appear above the body. The tail flows out to the southeast and then in multiple flowing arcs to the northeast and back around to the northwest.

I chose the 25 mm Plössl eyepiece to capture the full extent of nebulosity. The 10 mm Plössl framed the swan area nicely, but didn't allow a full view of the extended nebulosity. I tried the 32 mm Plössl with a 2X barlow, and this would have been a perfect scale for the nebula, but this eyepiece combination caused too much glow around star groups to give a good look at faint nebulosity. There was a bright yellow-orange star to the northwest of the nebula as noted in the sketch. This sketch took 2 hours to complete, but the sky was clear and the experience was enjoyable. My only concern was that it would sink too far into the murk in the southwest before I finished. 172 stars are plotted in the sketch.

Sketch/DSS Photo Comparison of Messier 17 (M17 - Swan Nebula)

Sketch/DSS Photo Comparison of Messier 17 (The Swan Nebula)

Object Information:

M17 is a region of star formation that shines by excited emission of light from radiant young stars within. The stars that heat and illuminate this nebula aren't readily visible to the eye, or photographically, but are hidden within. It is estimated that a small cluster of about 35 of these stars are imbedded in the nebulosity.

Photographically, the color of the Swan Nebula is reddish. This color comes from the hot hydrogen gas excited to shine by the hottest stars which have just formed within the nebula. However, the brightest region is actually a white color. This white color isn't just a photographic overexposure as I had thought, but is apparently a result of a mixture of red emission light, together with reflections of the bright star light from the dust in that region. The nebula also contains a large amount of dark obscuring dust, which is responsible for giving it its distinctive shape. However, even this dark dust is glowing brightly in the infrared spectrum, heated by hidden young stars.

The bright portion of the nebula extends roughly 15 light years, but the total cloud seems to extend at least 40 light years. The amount of matter in the cloud is estimated at about 800 times that of the Sun, which makes it more massive than the fantastic Orion Nebula (M42). It's estimated that M17 is 5,000 to 6,000 light years away. It was discovered by Philippe Loys de Chéseaux in 1745-46, but wasn't widely known, and so rediscovered by Charles Messier in 1764. Under very favorable conditions, M17 is just visible to the naked eye.

This object is known by a number of common names: Swan, Checkmark, Horseshoe, Omega. It is also catalogued as: Cr 377, Lund 827, LBN 60, Sh2-45, h 2008, GC 4403, OCL 44.

SubjectM17 (NGC 6618)
ClassificationEmission Nebula (III 3 m n)
PositionSagittarius [RA: 18:20:47 / Dec: -16:10:18]*
Size*20' x 15''
Brightness*6.0 bMag
Date/TimeAugust 27, 2006 - 10:05 PM to 12:10 AM MST (August 28, 2006 - 05:05 - 07:10 UT)
Observing Loc.Anderson Mesa, AZ
InstrumentOrion SVP 6LT Reflector (150 mm dia./1200 mm F/L)
Eyepieces/Mag.25 mm (48 X), Orion Ultrablock filter
ConditionsClear, calm, 50°F
Seeing5/10 Pickering
TransparencyMag 6.8+
Sources>SEDS
NGC/IC Project, DSS

* Based on published data.


October 30, 2004 Observation

Observation Notes:

I remember the first time I looked at this nebula, the first thing I saw was a straight swoosh, which was cool in itself. But I was encouraged to look closer for some more features, and sure enough, the hook on the west side emerged into view. Once you see that feature, the "Swan Nebula" name makes perfect sense. It's also called the "Omega Nebula", but at best, it only looks like 2/3 of an Omega to me. So, the Swan it is as far as I'm concerned. It appears to be swimming to the west with its base on the north side (fortunately, my newtonian reflector rotates the image 180 degrees so I can get the full effect). The overall width of the nebula that I could see, appeared to be 14' with the brighter portion being 9' across. The brightest is along the upper back of the swan. There is a gap in brightness between the western body, and the curve of the neck. The neck brightens a bit as you head south, then dims at the top, before brightening again at the head. The east end of the body fans delicately to nothing. The north (bottom) of the swan body has the sharpest drop in brightness, as though sitting in water, while the south (top) of the body is a bit more diffuse. The Orion Ultrablock filter really helps bring out the details in the nebula. But I did need to remove it to get a better look at the dimmer stars. There is one star right in the position where the eye would be. This is a beautiful and delicate nebula that is a treat to look at. It's a bummer that light polution made it difficult to see the dimmer portions.

Date/Time10/30/04 - 7:40 PM
Observing Loc.Flagstaff, AZ - Home
InstrumentOrion SVP 6LT Reflector (150 mm dia./1200 mm F/L)
Eyepieces/Mag.25 mm (48 X), 25 mm + 2X Barlow (96 X), 10 mm (120X), Orion Ultrablock filter
Seeing3/10 (based on Altair)
TransparencyMag 5.8 (based on Ursa Minor)

* Based on published data.

5 Comments

I first saw this report at CloudyNights.com (Oct. 30). I didn't reply then, but I better let you know that I love your reports and reporting style. The humor you give to your writing while giving the facts at the same time is just excellent, a perfect combo.

I always wondered why people use to call this nebula the "swan" when I couldn't see the duckie in there (I preferred to call it "The Check Mark Nebula" instead). Your sketch was the first one to make it "visible" to me, so thank you. After that, I've been able to see the figure even in a sketch I did a decade ago (that you can find at http://www.fractovia.org/astronomia/messier/html/m017.html ). Now I know why I failed to see the swan before, and that's because I was "looking" in the wrong direction (I thought the head and neck were a wing while the duck's butt was actually the head...

Juan, thank you, I'm glad you enjoy the observations. I just had a chance to check your site. Your rendering of M17 is incredible, as is the rest of the site. I'm looking forward to exploring it some more. My Spanish is a little weak, but your descriptions are clear enough that I can pick it up. With your rendering of M17, you've captured a great deal of soft detail that I didn't see the night I observed. I hope to try and catch it again next summer when it's higher in the sky, and from a darker site.

Thanks again,
Jeremy

Hi Jeremy,
I like the way that you show your readers,exactly the way that you see it through a eye piece!.
Very nicely done!!!.

Andrew, thanks! M17 is one of those objects that begs to be observed at several magnifications. With this wide view cared for, I feel like I'll need to go back in for another close look and do it more justice at 120X or perhaps 240X to really dig into some of the complex, mottled detail that I didn't get the first time around. If I ever get my hands on a ~16 mm eyepiece with a 3/4° TFOV, that would be perfect too.

Hi Jeremy,
As you know,I take most all of my images using prime focus.This neb as you say "begs to viewed at different mags" is an object worthy of eye piece projection.When the skies clear and the moon isn't so bright I will give it another try.Although,time is running out and it will beging to set early.
